1. Application for: Agricultural machines, carrier vehicles, construction machines, such as combine harvesters, cranes,
bulldozers, excavators.
2. Black color or white color or grey color available .
3. Conventional type or interchangeable type is available .
4. When you send an inquiry, please list width *pitch*links, it is better to be with the fitted machines' name and model number
(1)Rubber track is a whole continuous track made of rubber mould. The center is strengthened by fabric and multiple wire ropes. There is a shoe thorn on the outside and a transmission part on the inside.Steel drives are embedded in vulcanized rubber.The main parameters of rubber track are pitch, pitch number, track width, pattern, embedded metal pattern, etc.
(2) the drive wheel is installed on the walking reducer to wind the track to ensure the mechanical operation.The drive wheel for rubber track adopts convex tooth shape with pitch of 128mm.There is bending stress during track work, which may cause track fatigue damage. Therefore, the diameter of the drive wheel is not easy to be too small.
(3) supporting wheel, supporting wheel and guide wheel are mounted on both sides of the track teeth and pressed on the rubber plane respectively. In order to prevent damage caused by rim cutting and severe extrusion of rubber, the rim is wider: because of the high track teeth, the wheel body is larger.
